PP Biaxial Geogrid 30-30 kN/M

Biaxial polypropylene geogrids are called PP biaxial geogrids because they contain similar strength in both the machine and cross machine direction. It does not necessarily mean they have the same strength in both directions just that the geogrids are designed to provide support in both directions. Biaxial geogrid can be knitted, woven or extruded but the majority are extruded. Extruded biaxial geogrids are generally extruded using polypropylene with a small amount of carbon black added to give the geogrid the ability to resist UV degradation. Biaxial geogrid’s primary application is for use in base stabilization. By placing the PP geogrid in the gravel base so that it can interlock with gravel above and below you can extend the service life or reduce the total amount of aggregate needed for a road or parking lot application.

• designed exclusively for ground stabilization
• more suitable for mechanical stabilization than woven and bonded geogrids
• strong junctions and sharp rib edges for effective confinement of the aggregate particles

Performance:

High tensile strength at both longitudinal and transverse direction

Application:

1. It can be applied in all kinds of roads, railways, airports to enhance the roadbed.

2. It can be applied in a large car park and terminal freight yard, etc. to strengthen the foundations of a permanent load;

3. It can be applied in rail, road slope’s protection;

4. It can be applied to enhance the culvert;

5. It can be applied as a secondary enhancement after the uniaxial geogrid soil enhancement, further enhancement to the

soil; prevent soil erosion;

6. It can be applied in mining, tunnel reinforcement.

Benefits:

1. Increase the bearing capacity of the roadbed and foundation and prolong their service life.

2. Prevent road surface and foundation from sinking or flawing, keep clean and beautiful ground surface.

3. Convenient construction saves time and labor, reduce mounting time and decrease maintenance expense.

4. Prevent culverts from flawing.

5. Enhance earth slope and prevent water loss and soil erosion.

6. Decrease underlayer thickness and save manufacturing cost.

7. Enhance the stability of side slope turf net patch to improve greening.

8. Replace wire netting used in mine as intermediate ceiling netting.

Specification:                                                          PP Biaxial Geogrid 30/30 kN/M

Index Properties Test Method Unit MD Values TD Values  Polymer – – PP –  Minimum Carbon Black ASTM D 4218 % 2 –  Tensile Strength @ 2% Strain ASTM D 6637 kN/m 10.5 10.5  Tensile Strength @ 5% Strain ASTM D 6637 kN/m 21 21  Ultimate Tensile Strength ASTM D 6637 kN/m 30 30 Structural Integrity  Junction Effciency GRI GG2 % 93 93  Flexural Rigidity ASTM D 7748 mg-cm 200,000 –  Aperture Stability ASTM D 7864 m-N/deg 0.75 – Dimensions  Roll Width – m 3.95 or 5.95 –  Roll Length – m 50 –
